Ringlock system is one of the efficient modular scaffolding systems, which consists of hot-dipped galvanized, high-strength steel modular components. The steel modular components can be divided into scaffolding planks, scaffolding tubes, and scaffolding couplers.

The galvanized steel modular components are assembled together by integral wedge connectors. The ring lock system has vertical members with integral rosette connections welded to them at 500mm spacings.

The horizontal ledgers, transoms and diagonal braces are secured to the rosettes on the vertical scaffolding tubes by means of wedge heads that incorporate captive wedges.

The rosette has four narrow holes and four larger holes. The four narrow holes position the ledgers automatically and securely at right angles after the wedge is secured.

 The four large holes permit the alignment of ledgers and diagonal braces at the required angle. The versatility of the Ringlock System allows for straight, curved or circular configurations, for both access and support and also for independent and mobile towers.

The simple and rapid assembly of this system offers cost and time savings. With the universal joint and interchangeable elements, this system can be used in a wide variety of projects for falsework or shoring.
