Steel grating is made of flat steel which is crossing arranged with ledgers according to a certain space. It is an iron product which has welded rectangular grids on the surface. With a simple comparison, the differences can be seen clearly between the two of catwalk plank and steel grating.

For the steel grating:

Specification: 0.7 m2/ piece                   Maximum load bearing: over 2500kg

Self weight: 5.7 kg/piece                      Portable type: easy to carry

Raw Material: 7mm hot rolled deformed bar with a strength of more than 550 Mpa.

Surface material: Galvanization

Plank space: vertical space of 4.3cm and transverse space of 33.33cm.

Investment and recycling value: available to be recycled, solid and low loss on the cost.

For steel scaffolding planks:

Specification: 0.7 m2/ piece                   Maximum load bearing: 600kg

Self weight: 10-12 kg/piece                    Portable type: hard to carry

Raw Material: steel plate

Plank space: 50cm middle bracing space.

Investment and recycling value: available to be recycled, solid and low loss on the cost.
