To prevent uneven steel tube into the ground, cause body tilt, the collapse of the serious consequences, it should be according to the height of scaffolding, to determine the stud base handling.

First foundation treatment should be solid and reliable, and the thickness of the plate is not less than 50 mm, length of not less than 2 m long, laid on every board not less than 2 root poling, laid flat, shall not be suspended, scaffolding nails fastened on the skid base application, such as the use of reinforced concrete beam not only the bottom plate.

Should be set around the ringlock scaffolding drain or in the surrounding pouring concrete aproll slope. If not set drainage facilities, when the wet homework or rainy weather, a lot of water sediment in scaffolding foundation, under the action of load, the soil quality progressively, settlement. Scaffolding will happen uneven subsidence, leading to a serious distortion, the frame body tilt.

Currently using foot hand pipe is Φ 48 x 3.5 mm ordinary low carbon high frequency welding steel pipe, its cross section is very small, vertical pole is the main force of the ringlock scaffold pole piece, its role is to scaffolding by large and small slider on the load transfer to the basics of poling, through the base, on the plate to the foundation. Must ensure the quality of vertical stem base, meet the requirements of scaffolding foundation bearing capacity, when it is necessary to take measures to enhance the whole stiffness of scaffold based.

Due to unreasonable requirements of construction progress and construction technology for a variety of reasons, such as building foundation or underground engineering also trough after the soil cannot be backfill compaction, step by step according to the requirements of specification need to reach scaffolding foundation bearing capacity.
