Requirements on the indoor decoration scaffolding structure.

Time:2015/11/12

First of all, use the single standing tubes with a transverse space and longitudinal space of 1.5m and the space between the standing

tubes and the wall body shall be 300mm. The distance from each scaffolding joint center to the nearest main joints shall be no bigger

scaffold for sale



than 1/3 the space between standing tubes. And the connection joints of adjacent standing tubes shall be staggered arranged in

different spans. For the two adjacent standing tubes within different spans and lifts, the staggered space shall be no smaller than

500mm. Then, all the standing tubes shall be fastened and fixed to the horizontal tubes with right angle couplers as the horizontal tubes

function as binding parts which can assure the load bearing capacity of the standing tubes. The shall be no omission or neglect of the

setting of scaffolding for sale standing tubes and they shall not be erected every step.

scaffold for sale

Lastly, the bridging braces shall connect to 6 standing tubes with an inclined angle of 45-60 to the ground and shall arranged

successively along the frame height.
